How is circuit board copying done?

The technical realization process of PCB copying is simple, that is, first scan the circuit board to be copied, record the detailed position of the components, then disassemble the components to make a Bill of materials and arrange material procurement, then scan the blank board into a picture and restore it to a pcb board drawing file after board copying software processing, and then send the PCB file to the plate manufacturer for board making. After the board is made, weld the purchased components to the made PCB board, Then go through the circuit board and debugging.



Information required for circuit board copying



A set of templates is required for simple single and double sided boards. If it is a multi-layer board, it is best to provide two identical sets of templates.



How to calculate the price of circuit board copying?



The price of circuit board copying is commonly quoted in the industry based on the number of pins (PINs), wiring quantity, silk screen printing, etc. on the circuit board that needs to be copied, and combined with the difficulty of the PCB board. The price of circuit board copying generally depends on the size of the PCB board, the number of layers of the PCB board, the density of components, and the ease of operation.
